50 mph.... how to get there

Posted: Tue Jul 10, 2012 9:13 pm Post subject: Re: 50 mph.... how to get there

I was confident you would squeeze a couple more mph out of it with the tailgate removed.
Do you have the front windshield open for air flow to the engine? A 1 ½ inch diameter hole in the windshield can cost you about 1.5 mph even with the tailgate removed. Doesn’t seem like much but every little bit helps when going for top speed.

Posted: Tue Jul 10, 2012 9:21 pm Post subject: Re: 50 mph.... how to get there

I have to say thank you Snookman for the lightened pawl idea, it did work!

As for the windshield no there are no holes

Posted: Tue Jul 10, 2012 9:25 pm Post subject: Re: 50 mph.... how to get there

I could not have reached 55mph much less 50 without Robins help.... Thank You dude Very Happy

By the way anyone wondering, my motor was not modded for topend it was modded for low end, but theres a catch to how I reached 55mph.

One thing will remain secret Wink

Videos · Posted: Tue Jul 10, 2012 9:39 pm Post subject: Re: 50 mph.... how to get there

Posted: Tue Jul 10, 2012 9:54 pm Post subject: Re: 50 mph.... how to get there

Posted: Tue Jul 10, 2012 9:55 pm Post subject: Re: 50 mph.... how to get there

Just curious. Why do you have two different diffs, one BP vorza and one BP savage x? Is that by design and if so could you explain the benefits.

Posted: Tue Jul 10, 2012 10:01 pm Post subject: Re: 50 mph.... how to get there

I chose this setup to test the vorza diff housing compared to the alloy cup. To see which bearing would fail faster. Im using the new savage X sintered BP ring gears on both. They also have the HB steel bevel gears.

Posted: Tue Jul 10, 2012 10:12 pm Post subject: Re: 50 mph.... how to get there

Posted: Tue Jul 10, 2012 10:36 pm Post subject: Re: 50 mph.... how to get there

Haha no I still have 3 shims and running 30%

Wait I just caught that AHAHAHAHAHAHAHAHAHAHAHAHAHAHA Dude no way they will reach it with what ive seen

Posted: Tue Jul 10, 2012 11:06 pm Post subject: Re: 50 mph.... how to get there

Posted: Wed Jul 11, 2012 1:03 am Post subject: Re: 50 mph.... how to get there

55mph,,That's pretty impressive,,
Are still tinkering for more?

You have to go for more,,Right?
I would want to,,,,,,It would consume my Thought's...
How do you sleep at night?
When was the last youve eaten?

The only way you can relieve Your brain is by releasing your secret's..
I'm willing to carry the burden for you,,,just tell me,,you will feel better Wink

Posted: Wed Jul 11, 2012 5:42 am Post subject: Re: 50 mph.... how to get there

LOL believe it or not its all I could think about last night. Will I go for more, yes, but right now ive set the bar extremely high. My next step is to try the 22t CB. The motor will either push the gearing or wont. Based off what I saw yesterday, it certianly has the power but its reaching it limit on rpm. When I hit 55 you can hear the motor reach rpm it didnt the entire run. Maybe I might have to shorten the header again.

Time will tell.... just remember it goes 55mph up hill :wink:

The secrets are inside the motor Cool

Posted: Wed Jul 11, 2012 6:42 am Post subject: Re: 50 mph.... how to get there

Nice job. This should reopen some discussion with assassin huh? I've been following that with great amusement.

Posted: Wed Jul 11, 2012 7:23 am Post subject: Re: 50 mph.... how to get there

LoL... Read his comment on my new video. Hahahahahahaha he talks all this crap now says I told you so, really?!?!

He will always be a hater. Notice where's his video at...

Posted: Thu Jul 12, 2012 2:53 pm Post subject: Re: 50 mph.... how to get there

Just bought the traxxas 22t CB and a Motor Saver Airfilter.

Im hoping I can squeeze out 56mph with a cold plug installed. I think the new goal might be 57 or 58mph with the new CB and airfilter.

Its a larger jump in speed changing the CB verses the Spur so hopefully I still have plenty of low end to push this new gearing.

HAHA the gear ratio will be 1.95 WOW thats stupid high, Right now its 2.15

Imagine if I had Robin mod me a top speed motor....hmm I wonder if 60mph is achieveable? I mean afterall mines not a top end motor, its a ballz out power motor Shocked

Posted: Thu Jul 12, 2012 3:53 pm Post subject: Re: 50 mph.... how to get there

What bell did you buy? The only traxxas 22T bells I know of are mod .8

Posted: Thu Jul 12, 2012 5:14 pm Post subject: Re: 50 mph.... how to get there

4907 t maxx bell. The picture looks like its mod 1

Do you know of a 22t mod bell vented?

http://www.ebay.com/itm/140782799033?ssPageName=STRK:MEWNX:IT&_trksid=p3984.m1497.l2649

Posted: Thu Jul 12, 2012 6:04 pm Post subject: Re: 50 mph.... how to get there

This is a mod 1 revo 40t revo spur. I would have to mod it to fit the savage tranny tho

http://www.amazon.com/T3219-Steel-Spur-Gear-Revo/dp/B000M5BSXQ

Would this work?

http://www.ebay.com/itm/Traxxas-5309-Revo-3-3-Transmission-Slipper-Clutch-38-Tooth-Spur-Gear-38t-M1-3954-/380451326299?pt=Radio_Control_Parts_Accessories&hash=item5894aa895b

Im thinking that I can use the revo slipper with the HR steel 38t spur paired with my HPI 20t cb. The the final ratio would be 1.9:1

Posted: Thu Jul 12, 2012 6:27 pm Post subject: Re: 50 mph.... how to get there

You will have to look very hard to find a standard 22T bell in mod 1 vented or non vented.
It should be pretty easy to fit the revo spur to the stock slipper or mod the revo slipper to fit the tranny input. Doing speed runs you really dont need a slipper. I'm running an 18T bell and 22T spur on the twin rig without a slipper.
I dont really see the need for a steel spur either, grab a stock 36T revo spur and see how it works and then get a steel if needed.

Posted: Thu Jul 12, 2012 7:14 pm Post subject: Re: 50 mph.... how to get there

36t would bring me to 1.8:1 which is super high and I dont know if I have the torque to push it

How would you mount the spur to the savage slipper? Would you just drill 3 holes into the plate and bolt it to the spur?

My slipper right now is tightened all the way down but it still slips. So if it was eleminated I could theoretically put more power to the wheels?
