How To: LST Shock Mod

Posted: Mon Nov 10, 2008 11:20 am Post subject: Re: How To: LST Shock Mod

SV250, is that how you run your lst's with all that pretention? Shocked

Posted: Tue Nov 11, 2008 2:42 am Post subject: Re: How To: LST Shock Mod

Posted: Tue Nov 25, 2008 8:13 pm Post subject: Re: How To: LST Shock Mod

THis was very very imformitive thanks alot!!!!

Posted: Wed Nov 26, 2008 2:01 pm Post subject: Re: How To: LST Shock Mod

No, I dont run them like that. The collar was all the way down for the pic. I was trying to show the top when I took it.

Posted: Mon Dec 01, 2008 12:36 pm Post subject: Re: How To: LST Shock Mod

Can anyone confirm that the X conversion kit from Innovative RC would work on a Savage XL?

Posted: Mon Dec 01, 2008 1:00 pm Post subject: Re: How To: LST Shock Mod

Get a hold of Rob at IRC and ask him. Order it and get a tracking# all while you have his attention. His cust service needs improvement. Other than that look up the part#s for the shock toers and a arms and see if they are the same.

Posted: Mon Dec 01, 2008 1:40 pm Post subject: Re: How To: LST Shock Mod

Posted: Mon Dec 01, 2008 1:53 pm Post subject: Re: How To: LST Shock Mod

Yeah it should work fine, and you can run the rear shocks on the front of the rear a-arms instead of using the tierod relocation bracket.

Posted: Thu Dec 04, 2008 3:45 am Post subject: Re: How To: LST Shock Mod

I might add a further and specific point - Kiz mentioned that the IRC shocks may not work with LST shock hop-ups. Well, based on info in this topic I ordered RcRaven springs from the states. Will get to those in a sec, but here is an important note:

IRC shocks will not accept LST springs. The IRC springs are thinner (not the actual metal, the overal width of the spring). This means that the IRC retainer will not hold any LST springs (including Ravens). I will investigate putting Losi retainers on the IRC shock (can't see a problem - even if the IRC shaft is thicker - whats the worst I need to do? slightly enlarge the hole in the Lost retainer? I honestly think this will do the trick and will also give me the ability to change IRC springs without removing the cap.

As for the Ravens.......obviously can't run them yet. Dropping the truck on the ground is enough for the spring to pop past the retainer. Now, I have a heavy rig. Proline 40 series w/ Moabs, IRC full extension, 250cc tank etc. There is absolutely NO NEED for any pre-load with the Ravens - and I couldn't be happier. I'm running 35wt oil and may go to 40-45. The springs are a lot stiffer than IRC's - which to be honest, are too weak unless you are running a light weight rig. All these comments around springs are based on the intention of having the driveshafts/dogbones horizontal when the truck is sitting. To do this with the IRC shocks/springs, you need a bit of pre-load and the spring isn't stiff enough to stop bottoming out over even the smallest of drop/jump.

So......hopefully tomorrow I can pick up some Losi retainers and fit them tomorrow night and give it a try. Personally, I'm pretty confident.

Now that I've done the IRC shock mod and waited so long for them to be instock - if someoneis after doing this conversion, I'd recommend sourcing Aftershock/LST2 shocks and running Ravens. For a big jumping and/or heavy truck, I think that would be the best combo.

Is it that much better than the stock 8 plastic HPI shocks - well, the jury may be out and I suspect that it will be horses for courses. However, I like the look, less maintenence (4 shocks vs Cool

, and with the Ravens - the stiffness required for a heavy truck.

Hope this helps folks.

Posted: Thu Dec 04, 2008 12:11 pm Post subject: Re: How To: LST Shock Mod

A quick note - IRC sell retainers to fit LST springs. I should have mentioned that before. Glad you like your shocks though, zoo. I'll add this in the main post.

Posted: Thu Dec 04, 2008 4:59 pm Post subject: Re: How To: LST Shock Mod

I noticed that IRC sells those retainers after my post. Will still try to get a hold of Losi retainers today.

Edit:

Well, got a hold of Losi retainers today. BTW - RCHobbies (Sydney folk) has a fantastic new and much larger store. All I can say is - what a breeze. Fitted the Raven springs and IRC shocks perfectly. Now the IRC is a truly great shock(with the right springs) and with no preload will maintain a slightly raised (from dog bone horizontal) stance after compressing. Brilliant. Very happy.

For those with IRC shocks and looking at fitting LST style aftermarket springs - I'd recommend the Losi retainers (part number LOSB2900 I think) as unlike Robs LST spring retainers, they can easily be popped off to remove the spring. (Sorry Rob Laughing

).

Haven't ran yet, but the improvement over the IRC spring setup (I'm runnign 35wt) is substantial with the Ravens.

Posted: Sun Feb 08, 2009 3:13 pm Post subject: Re: How To: LST Shock Mod

I had a feeling 60wt was too much lol....was at the lhs and thought i would re build the stock shocks...so I asked (before researching on here) what would be a good all round oil??? They pointed to the 60wt....dang it...cant even take it back already filled the shocks.

Posted: Fri Feb 13, 2009 11:16 am Post subject: Re: How To: LST Shock Mod

Thanks for the info kiz. Rob had said that early january he would have a set of IRC black anno'd shocks ready and would save a pair for me but, 3-4 emails later and no response, I decided to go with the LST2 shocks. The blue works as far as color is concerned and I think ill just check into getting some alloy caps to match them. Thanks for the write up!

Posted: Mon Jun 01, 2009 8:49 am Post subject: Re: How To: LST Shock Mod

That Would Be a weird question but Kiz can you please tell me whats the difference between the x and 25 kit.I mean I have a 25 with Losi hard anodized shocks and IRC 21-25 mounting kit,This summer my bulkheads and shock towers would be X Type and can't i use my IRC 21-25 lst mountig kit with my new towers?

Posted: Mon Jun 01, 2009 9:40 am Post subject: Re: How To: LST Shock Mod

Posted: Mon Jun 01, 2009 1:20 pm Post subject: Re: How To: LST Shock Mod

Ok KIZ thanks for a quick reply.I will try it 15 days later and write the result here:)
And about shocks.Hard Anodized can be bought just for its colour under sun:)That looks awesome with ti-ni shafts and they are indestructable Twisted Evil

Posted: Mon Jun 01, 2009 2:06 pm Post subject: Re: How To: LST Shock Mod

Yes it will work, i had a 25 with the irc kit, then i got rid of it and got an x but kept the kit and my old arms off the 25. The upper irc mounts will fit the x towers, its a little tight but not too bad, just uses different holes in the mounts for the bolts to go through the towers. So there is really no need to buy the x upper mounts unless you just want to.

Posted: Sat Jun 20, 2009 12:54 am Post subject: Re: How To: LST Shock Mod

Posted: Tue Aug 04, 2009 2:37 pm Post subject: Re: How To: LST Shock Mod

Excellent write-up and thread KiZ, well done mate. Very helpful. But...
I've got GPM's "LST" shock which you didn't mention, hopefully not because they are crap.
I'd like to get the RCRaven springs and Losi's Ti-Ni shafts, do you or anyone else know if they will fit? Just want to find out before I fork out $35 for a set of springs, and $16ea for the shafts. Cheers.

Posted: Wed Aug 05, 2009 7:59 am Post subject: Re: How To: LST Shock Mod

Hm, I wasn't actually aware that GPM made LST shocks! If they are replica LST shocks, then the parts should fit no problem, however I can't tell how much license GPM has taken in to modifying the design. You could try emailing GPM to ask. Their email is: chinngai [at] netvigator [dot] com

With regards to quality, I would hope they aren't too bad. I have GPM shocks on my rc18 and they have been pretty much flawless since I bought them, several years ago now.
